Display + Keys Brick
Pictured with a 0.96 in OLED screen fitted.
Displays · SKU TP-D02
OLED screen plus a 5-way keypad – menus and games without using any board pins.
₹499
Works with TinkerPie V1 · same JST-PH cables as the board · Delivery across India: ₹100, 3–7 days · 7-day replacement for damaged or defective kits
About this kit
The Display + Keys Brick combines a socket for a 0.96 in 128 x 64 OLED screen with a five-way keypad: UP, DOWN, LEFT, RIGHT and OK. Key presses are debounced, repeat when a key is held and are stored until the program reads them, so students can build menus and games without using any board pins.
Features
- 0.96 in 128x64 OLED (SSD1306) socket
- 5 keys: UP, DOWN, LEFT, RIGHT, OK - debounced, with auto-repeat
- Key presses are stored until the program reads them
- Pin-order selector for any 0.96 in OLED
- BUS IN + BUS OUT
- I2C 0x3A (keys) + 0x3C (OLED)
Specifications
| Size | 64 x 40 mm |
|---|---|
| Display | 0.96 in OLED, I2C |
| Keys | 5 x 5 mm tactile |
| Interface | I2C 0x3A-0x3B + 0x3C |
| Brain | CH32V003 |
